The smallest model in Yamaha’s four-stroke lineup, the F2.5 has evolved for added efficiency and convenience. Efficient and reliable, this little wonder never ceases to amaze.
Oil Retention System: Yamaha’s exclusive Easy Storage Oil Retention System allows the engine to be stored on either side or on the front grip without any fear of oil leakage, assuring the engine is easy to start the first time out.
See-Through Tank: The built-in, see-through fuel tank lets boaters see fuel quantity at a glance, while the tank cap is designed to prevent water intrusion.
Easy Grip Knob: For simple operation, the starter knob, F-N gearshift lever and choke knob are all within easy reach.
2018 Yamaha F2.5 F2.5SMHB Outboard Motor
- Keep It Simple: A new Oil Filler Cap makes checking the oil level simple.
- Looking Good: The updated rounded cowling design keeps the engine consistent with the look of the Yamaha outboard lineup.
- Large Twist Throttle: The large twist throttle provides a more comfortable grip for operators.
- Carry On: A big carrying handle is designed to equilibrate the centre of gravity so the outboard can be lifted easier and maintain proper balance while being carried by one hand. The carrying handle can also be used to steer during reverse operation.
- Compact & Lightweight: A single-cylinder, OHV, splash lubrication and simple TCI (Transistor Controlled Ignition) system contribute to a compact and lightweight engine.
- Anti-Corrosion Protection: Yamaha’s unique YDC-30 aluminium alloy protects the engine’s exterior parts, while a zinc coating, high-quality stainless steel and 5-stage exterior coating offers long-lasting protection inside and out.
- Engine Type: 1 cylinder
- Displacement: 72cc (4.4ci)
- Bore & Stroke: 54x31mm (2.13×1.24 in.)
- RPM Range: 5,250-5,750
- Compression Ratio: 9.0:1
- Induction System: OHV (overhead valve)
- Fuel Delivery: Carburetor
- Starting: Manual
- Ignition: TCI
- Lubrication: Splash
- Degree of Trim/Tilt: 4 positions/ 80 deg.
- Exhaust: Above Prop
- Cooling: Water/Thermostatic Control
- Gear Shift: F/N
- Gear Ratio: 13/27 (2.08)
- Recommended Fuel: Regular Unleaded (Minimum Pump Octane 87)
- Recommended Oil: Yamalube 4-M FC-W 10W-30 or 20W-40
- Oil Capacity: .35L (.33 qt.)
- Shaft Length: 15 in.
- Dry Weight: 17 kg (37 lb.)
2018 Yamaha F2.5 F2.5SMHB Outboard Motor
| Engine | |
| Engine Type | 1 cylinder |
| Bore x Stroke | 54 x 31 mm (2.13 x 1.24 in.) |
| Displacement | 72 cc (4.4 ci) |
| Starting | Manual |
| Dimensions | |
| Shaft Length | 15 in. |
| Weight | 17 kg (37 lb.) |
| General | |
| Full Throttle Operating Range | 5,250-5,750 rpm |
| Gear Ratio / Shift | 13/27 (2.08) / F/N |
| Fuel Induction | OHV (overhead valve) |
| Cooling | Water/Thermostatic Control |
2018 Yamaha F2.5 F2.5SMHB Outboard Motor
WHAT’S IN THE BOX ?
1 X Outboard Motor
1 X Outboard Tiller Handle
1 X Fuel Tank
1 X Quick Connect Fuel Line tilt switch
1 x Teleflex SL3 Throttle control Top or side Mount + Free Installation Universal Cables
1 X Outboard Warranty Card from manufacturer Valid 5 Years Depending on outboard type
1 X Standart Aluminum Propeller Depending on outboard Brands , type & Horse power.
1 X Trim limiter
3 X Gall Free Oil Depending on outboard Brands Yamalube, Honda Marine Oil, Mercury Premium Oil
1 X Stainless Outboard Anti-Theft
1 X Book Owner’s Manual Guide from manufacturer
1 X Ebook Installation Guide & And how to take care of the engine properly.
3 X Cable Protection System Length 800mm
